n8n Introduction: Nodes, Triggers, and Expressions

n8n is a visual workflow editor. No coding required to build automations, but you can add custom code.

Core Concepts

Workflow

A workflow is a series of connected nodes that execute in sequence.

┌─────────────┐
│   Trigger   │  (listens for event)
└──────┬──────┘
       │
       ▼
┌──────────────────┐
│   Transform      │  (modify data)
└──────┬───────────┘
       │
       ▼
┌──────────────────┐
│   AI Processing  │  (call Ollama/Claude)
└──────┬───────────┘
       │
       ▼
┌──────────────────┐
│   Output         │  (save/send result)
└──────────────────┘

Node

A node is a unit of work. Types:

Trigger: Starts the workflow (webhook, schedule, file change)
Action: Does something (call API, send email, query database)
Control: Logic (if/else, loop, wait)
Transform: Modify data (set variables, map, format)

Connection

Edges between nodes pass data forward.

Node A output → Node B input

Data flows as JSON objects.

Triggers

A trigger starts the workflow.

Webhook Trigger

Listen for HTTP requests.

Trigger: Webhook
├─ HTTP Method: POST
├─ Path: /chat
└─ Listen for requests at: http://your-server:5678/webhook/chat

Activate workflow to generate the webhook URL.

Example payload:

{
  "message": "What is Docker?"
}

Schedule Trigger

Run on a timer.

Trigger: Schedule
├─ Trigger type: Every hours
├─ Interval: 1
└─ Runs every hour

Cron syntax for complex schedules:

0 9 * * * = Every day at 9:00 AM
0 */4 * * * = Every 4 hours
0 0 1 * * = First of every month

File Trigger

React to file changes.

Trigger: Watch Directory
├─ Path: /uploads/
├─ Trigger on: New file
└─ Process each new file

Nodes: Structure & Execution

Node Anatomy

┌───────────────────────┐
│    Node Header        │
├───────────────────────┤
│ Node Type             │
├───────────────────────┤
│ Input Fields          │
│ • Name                │
│ • Value               │
├───────────────────────┤
│ Output Preview        │
│ { "result": "..." }   │
└───────────────────────┘

Common Nodes

Node	Purpose	Input	Output
Set	Assign variables	Key-value pairs	Object with keys
HTTP Request	Call API	URL, method, body	Response JSON
Ollama	LLM inference	Prompt, model	Generated text
If	Conditional logic	Condition	True/false branch
Loop	Repeat over array	Array items	Each item
Code	JavaScript code	Input object	Transformed output
Database	Query database	Query, values	Result rows
Send Email	Send email	To, subject, body	Status

Data & Expressions

Basic Expression

Reference data from previous nodes.

{{ $json.message }}          # From input payload
{{ $json.user.name }}        # Nested property
{{ $json.0.id }}             # Array element
{{ $now.format('YYYY-MM-DD') }}  # Current date

Transform Expression (= Prefix)

Perform calculations. CRITICAL in n8n 2.x: Use = prefix!

# WRONG (n8n 2.x):
"prompt": "{{ $json.message }}"
# Result: literal string "{{ $json.message }}"

# CORRECT (n8n 2.x):
"prompt": "={{ $json.message }}"
# Result: actual message content

Why? Without =, n8n treats it as plain text. With =, n8n evaluates as JavaScript.

Expression Examples

# Arithmetic
={{ $json.count + 1 }}                    # Add 1
={{ $json.price * 0.9 }}                  # Apply discount

# String
={{ $json.name.toUpperCase() }}           # Uppercase
={{ $json.text.slice(0, 100) }}           # First 100 chars
={{ $json.items.join(', ') }}             # Join array

# Array
={{ $json.items.length }}                 # Array length
={{ $json.items.filter(x => x.active) }}  # Filter
={{ $json.items.map(x => x.name) }}       # Transform

# Conditional
={{ $json.status === 'pending' ? 'Waiting' : 'Done' }}

# Date (Luxon library)
={{ $now.toISO() }}                       # ISO 8601
={{ $now.minus({days: 7}).toISODate() }}  # 7 days ago
={{ $now.toFormat('yyyy-MM-dd HH:mm') }}  # Custom format

Date Formatting (Luxon, NOT Moment.js)

CRITICAL in n8n 2.x: Use Luxon, not Moment!

# WRONG:
$now.format('YYYY-MM-DD')  # Outputs: YYYY-03-DD (literal!)

# CORRECT:
$now.format('yyyy-MM-dd')  # Outputs: 2026-03-21

Luxon key differences:

yyyy = 4-digit year
MM = 2-digit month
dd = 2-digit day
HH = 24-hour format
hh = 12-hour format

AI Nodes

Ollama Node

Run local LLM.

Ollama
├─ Base URL: http://ollama:11434
├─ Model: mistral
├─ Prompt: ={{ $json.question }}
├─ Temperature: 0.7
└─ Output: $json.response

Claude API Node (via HTTP)

Call Claude via REST API.

HTTP Request
├─ Method: POST
├─ URL: https://api.anthropic.com/v1/messages
├─ Headers:
│  ├─ x-api-key: ={{ $env.ANTHROPIC_API_KEY }}
│  └─ content-type: application/json
└─ Body: ={
    "model": "claude-opus",
    "messages": [{"role": "user", "content": "{{ $json.question }}"}],
    "max_tokens": 1024
   }

OpenAI Node

Call GPT API.

OpenAI Completion
├─ API Key: ={{ $env.OPENAI_API_KEY }}
├─ Model: gpt-3.5-turbo
├─ Prompt: ={{ $json.question }}
└─ Output: $json.choices.0.message.content

Control Flow

If Node

Conditional branching.

If Node
├─ Condition: {{ $json.status }} === 'error'
│
├─ TRUE branch:
│  └─ Send error email
│
└─ FALSE branch:
   └─ Continue processing

Loop Node (Item Lists)

Process array of items.

Item Lists
├─ Mode: Split Out Items
├─ Array: {{ $json.items }}
│
└─ Creates multiple executions, one per item
   └─ Each execution processes $json.item

Example:

Webhook receives: [{"name": "Alice"}, {"name": "Bob"}]
  ↓
Item Lists splits into 2 executions
  ↓
Execution 1: Send email to Alice
Execution 2: Send email to Bob

Wait Node

Pause execution.

Wait
├─ Amount: 5
├─ Unit: seconds
└─ (waits 5 seconds, then continues)

Or wait for condition:

Wait
├─ Mode: Until date/time
└─ Target date: {{ $json.scheduled_time }}

Set Node (Variables)

Define working data.

Set Node
├─ Keys:
│  ├─ user_name: ={{ $json.user.name }}
│  ├─ is_admin: ={{ $json.role === 'admin' }}
│  ├─ timestamp: ={{ $now.toISO() }}
│  └─ message: ={{ 'User ' + $json.user.name + ' logged in' }}
│
└─ Output object:
   {
     "user_name": "Alice",
     "is_admin": true,
     "timestamp": "2026-03-21T10:15:00Z",
     "message": "User Alice logged in"
   }

Error Handling

Workflows can fail. Handle gracefully.

Try-Catch Pattern

Node A (risky)
├─ On error: Continue (or stop)
│
└─ If error:
   └─ Error Handler Node
      ├─ Send error email
      ├─ Log to database
      └─ Notify user

Conditional Error Handling

HTTP Request
├─ On error: Continue
│
If Node:
├─ Condition: {{ $json.statusCode === 404 }}
├─ TRUE: Handle not found
└─ FALSE: Handle other errors

Example: Complete Workflow

"Classify Email & Route"

Trigger: Webhook receives email
  ↓
Set: Parse email fields
  ├─ from: {{ $json.from }}
  ├─ subject: {{ $json.subject }}
  └─ body: {{ $json.body }}
  ↓
Ollama: Classify content
  ├─ Prompt: "Classify as: bug, feature, question\n{{ $json.body }}"
  └─ Output: category
  ↓
If: Check category
  ├─ Bug → Send to GitHub (HTTP Request)
  ├─ Feature → Save to Airtable (Airtable node)
  └─ Question → Send to support team (Email)
  ↓
Send Email: Confirmation to sender
  └─ "Received as {{ $json.category }}"

Best Practices

Use variable names, not nested paths

# Good
Set: user_id = {{ $json.user.id }}
Later: {{ $json.user_id }}  # Clear

# Confusing
{{ $json.data.response.user.id.value }}

Add notes to complex nodes
- Click node → Edit Fields → Add description
- "This Ollama call extracts entities from user input"
Test with sample data
- "Test" button → provide sample JSON
- Verify output before activating
Monitor workflows
- Executions tab shows run history
- Check logs for errors
- Set error handlers

Use environment variables for secrets

# .env file
ANTHROPIC_API_KEY=sk-...
OLLAMA_URL=http://ollama:11434

# In workflow:
{{ $env.ANTHROPIC_API_KEY }}

Checklist
