Stable Diffusion shows how to make complex generative models practical by working in latent space (not image space).

The Problem with Diffusion

Original diffusion models (DDPM, 2020) were extremely slow:

Training:
- Train on 512x512 images
- That's 262,144 pixels
- Requires ~1000 diffusion steps
- Very memory-intensive

Inference:
- 50-1000 iterations to generate image
- On GPU: 30+ seconds per image
- On CPU: Minutes

Stable Diffusion's solution: Don't work in image space—work in latent space (VAE).

Architecture: VAE + Diffusion + CLIP

Step 1: VAE Encoder
Input: 512x512 RGB image
Output: 64x64x4 latent

Step 2: Diffusion in latent space
Noise + denoise (4x less data)

Step 3: CLIP encoding (text)
Input: "A cat on a sunny beach"
Output: 768-dim embedding

Step 4: U-Net with cross-attention
Combine latent + CLIP

Step 5: VAE Decoder
Input: 64x64x4 latent
Output: 512x512 image

VAE (Variational Autoencoder)

Compression trick:

Encoder: 512x512 → 64x64x4
- 8x8x4 compression
- Lossless (with quantization)

Advantages:
- 64x fewer parameters
- 64x faster
- Diffusion practical

CLIP: Text Encoder

Input: "A cat on a sunny beach"
Processing:
1. Tokenize (BPE)
2. Transformer encoder
3. Output: 768-dim embedding

This embedding conditions the U-Net.

CLIP was trained on billions of image-text pairs, making embeddings very meaningful.

U-Net with Cross-Attention

def forward(latent, timestep, clip_embedding):
    x = latent
    for block in encoder_blocks:
        x = block(x, timestep, clip_embedding)  # Cross-Attention!
    noise_pred = decoder(x)
    return noise_pred

Cross-attention is efficient because CLIP is small (77 tokens) while latent is large (4096 tokens).

Training vs. Inference

Training

Data: LAION-5B (5 billion image-text pairs)

1. Load image, encode to latent (VAE)
2. Sample random noise level t
3. Add noise: x_t = sqrt(alpha_t) * x + sqrt(1 - alpha_t) * noise
4. Ask model: "Remove noise"
5. Loss: MSE between predicted and actual noise

Inference

1. Start: Pure noise
2. Loop 50 steps:
   - Ask model: "What's less noisy?"
   - Subtract predicted noise
   - Reduce variance
3. After 50 steps: Decent image
4. VAE Decode: Latent → image
5. Output: 512x512 image

Evolution Chain

Stable Diffusion v1 (2022)

  • 860M parameters
  • Trained on LAION-5B subset
  • 4 GB model

Stable Diffusion v1.5 (2022)

  • Fine-tuned on better data
  • +5% better quality
  • Better anatomy

SDXL (2023)

  • 3.5B parameters (4x larger)
  • Two CLIP models
  • Better for 1024x1024

Stable Diffusion 3 (2024)

  • Switched U-Net to Diffusion Transformer
  • Better scaling properties
  • Better text alignment

Why Stable Diffusion is "Stable"

  1. Trained on publicly available data
  2. Model is open-source
  3. Runs locally (not API-dependent)
  4. No NSFW filters (user choice)
