The Model Context Protocol (MCP) enables Claude Code to connect to external tools, services, and data sources. This reference covers all aspects of MCP configuration and management.

What is MCP?

MCP is a standardized protocol that allows Claude Code to:

  • Access external tools and services
  • Query data sources and APIs
  • Extend capabilities without modifying Claude Code itself
  • Share tools across multiple applications

MCP servers act as intermediaries between Claude Code and external systems, providing a structured interface for tool discovery and execution.

Transport Types

Claude Code supports three transport mechanisms for connecting to MCP servers:

1. Standard Input/Output (stdio)

The most common transport type for local MCP servers.

Configuration Format:

{
  "mcpServers": {
    "server-name": {
      "command": "node",
      "args": ["/path/to/server.js"],
      "env": {
        "CUSTOM_VAR": "value"
      }
    }
  }
}

Key Fields:

  • command: Executable to run (node, python, npx, etc.)
  • args: Array of command-line arguments passed to the executable
  • env: Environment variables passed to the server process (optional)

Example - Running a Node.js MCP Server:

{
  "mcpServers": {
    "example-server": {
      "command": "node",
      "args": ["./dist/index.js"]
    }
  }
}

Example - Running a Python MCP Server:

{
  "mcpServers": {
    "python-server": {
      "command": "python",
      "args": ["-m", "mcp_server_module"]
    }
  }
}

Example - Using npx to Run from npm Registry:

{
  "mcpServers": {
    "registry-server": {
      "command": "npx",
      "args": ["-y", "npm-package-name"]
    }
  }
}

2. HTTP

For remote MCP servers accessible via HTTP or HTTPS.

Configuration Format:

{
  "mcpServers": {
    "remote-server": {
      "url": "http://example.com:3000"
    }
  }
}

Key Fields:

  • url: Full HTTP(S) URL to the MCP server endpoint, including protocol and port

Constraints:

  • Must be a valid, reachable HTTP(S) endpoint
  • Server must support the MCP protocol over HTTP
  • Network connectivity required at runtime

Example - Local HTTP Server:

{
  "mcpServers": {
    "local-http": {
      "url": "http://localhost:3000"
    }
  }
}

Example - Remote HTTPS Server:

{
  "mcpServers": {
    "cloud-server": {
      "url": "https://api.example.com/mcp"
    }
  }
}

3. Server-Sent Events (SSE)

For MCP servers accessed via Server-Sent Events, typically with HTTP POST for commands.

Configuration Format:

{
  "mcpServers": {
    "sse-server": {
      "url": "http://example.com:3000"
    }
  }
}

Key Fields:

  • url: HTTP(S) endpoint providing SSE and command submission

Usage Pattern:

  • Claude Code opens an SSE connection for receiving messages
  • Commands are sent via HTTP POST to the same endpoint
  • Server responds via SSE events

Example:

{
  "mcpServers": {
    "event-stream-server": {
      "url": "http://localhost:3000/sse"
    }
  }
}

Adding MCP Servers via CLI

The claude mcp add command configures new MCP servers interactively.

Basic Syntax:

claude mcp add

Flags and Options:

Flag Usage Example
--name <name> Server name (kebab-case, required) claude mcp add --name my-server
--command <cmd> Executable command --command node
--args <arg1> <arg2> Command arguments (space-separated) --args ./server.js --debug
--env <KEY=VALUE> Environment variables (repeatable) --env API_KEY=abc123 --env DEBUG=true
--url <url> HTTP/SSE server URL --url http://localhost:3000
--directory <path> Working directory for stdio server --directory /path/to/server
--managed Configure as managed server (org-wide) claude mcp add --managed --name shared-server

Examples:

Adding a Node.js server:

claude mcp add --name example-server --command node --args ./dist/index.js

Adding an HTTP server:

claude mcp add --name remote-api --url http://localhost:3000

Adding a server with environment variables:

claude mcp add --name db-server --command python --args -m mcp_server --env DATABASE_URL=postgres://localhost --env DEBUG=true

MCP Configuration Files

.mcp.json (Project-Level Configuration)

Located in the project root, tracks MCP servers specific to this project.

Purpose:

  • Version control for project-specific MCP servers
  • Shared across all team members who clone the repository
  • Read-only in most cases (managed by claude mcp add command)

Format:

{
  "mcpServers": {
    "server-name": {
      "command": "node",
      "args": ["./dist/index.js"]
    },
    "another-server": {
      "url": "http://localhost:3000"
    }
  }
}

Editing:

  • Can be manually edited if needed
  • Changes take effect after restarting Claude Code
  • Validate JSON syntax before saving

~/.claude/.mcp.json (User-Level Configuration)

Located in the user's home directory, tracks MCP servers available to all projects.

Purpose:

  • Personal MCP servers used across all projects
  • Not shared with team members
  • Persists across project switches

Directory Structure:

~/.claude/
├── .mcp.json
├── settings.json
└── other-config-files

Global Configuration

Claude Code merges MCP configurations from multiple sources:

  1. Managed Settings: Applied by organization (highest priority)
  2. User Settings (~/.claude/.mcp.json): Personal servers
  3. Project Settings (.mcp.json): Project-specific servers
  4. Command-line Flags: Temporary overrides (lowest priority)

Servers are identified by unique names. If the same name appears in multiple configurations, project-level takes precedence over user-level.

MCP Server Management

Listing Configured Servers

Command:

claude mcp list

Output: Shows all configured MCP servers with their transport type and status.

Example output:

Available MCP Servers:
  ✓ server-1 (stdio)  — node ./dist/index.js
  ✓ server-2 (http)   — http://localhost:3000
  ✗ broken-server (stdio) — Command failed to start

Status indicators:

  • ✓: Server is running and responding
  • ✗: Server failed to start or is unreachable
  • ?: Status unknown (typically during initialization)

Viewing Server Details

Command:

claude mcp get <server-name>

Output: Detailed configuration for a specific server.

Example:

claude mcp get my-server

Shows:

  • Transport type (stdio, http, sse)
  • Connection details (command/args or URL)
  • Environment variables (if applicable)
  • Status and health information
  • Available tools provided by this server

Removing Servers

Command:

claude mcp remove <server-name>

Effect:

  • Removes server from .mcp.json or ~/.claude/.mcp.json
  • Takes effect after Claude Code restart
  • Removes access to all tools provided by that server

Example:

claude mcp remove old-server

Checking Server Status

Command:

/status

Output in Claude Code REPL: Shows all configured servers and their current status, including:

  • Server name
  • Transport type
  • Runtime status (connected, failed, initializing)
  • Available tools and resources
  • Any initialization errors

Environment Variables in MCP

Environment variables allow MCP servers to access credentials, configuration, and context without hardcoding values.

Passing Environment Variables via Configuration

In .mcp.json or ~/.claude/.mcp.json:

{
  "mcpServers": {
    "api-server": {
      "command": "node",
      "args": ["./server.js"],
      "env": {
        "API_KEY": "abc123",
        "DATABASE_URL": "postgresql://localhost/mydb",
        "LOG_LEVEL": "debug",
        "CUSTOM_CONFIG": "value"
      }
    }
  }
}

Passing Environment Variables via CLI

Using the --env flag with claude mcp add:

claude mcp add --name server \
  --command node \
  --args ./server.js \
  --env API_KEY=abc123 \
  --env DEBUG=true \
  --env DATABASE_URL=postgres://localhost/mydb

Environment Variable Best Practices

Never hardcode secrets:

// WRONG
{
  "env": {
    "API_KEY": "sk-abc123secret"
  }
}

Instead, use system environment variables:

# In shell before running Claude Code
export API_KEY="sk-abc123secret"

Then reference in configuration:

// Shell will substitute the value
{
  "env": {
    "API_KEY": "$API_KEY"
  }
}

Or use a .env file (not committed to Git):

# .env file
API_KEY=sk-abc123secret
DATABASE_URL=postgresql://localhost/mydb

Then load before running Claude Code:

source .env
claude code

Common Environment Variables for MCP Servers

Variable Purpose Example
API_KEY Authentication token sk-abc123...
API_URL Remote service endpoint https://api.example.com
DATABASE_URL Database connection string postgresql://user:pass@localhost/db
DEBUG Enable debug logging true or false
LOG_LEVEL Logging verbosity debug, info, warn, error
CACHE_DIR Cache directory for server /tmp/mcp-cache
TIMEOUT Connection timeout in seconds 30
MAX_RETRIES Retry attempts for failures 3

OAuth in MCP

Some MCP servers use OAuth 2.0 for authentication with external services (GitHub, Google, Slack, etc.).

How OAuth Flows Work with MCP

  1. Server Initiation: MCP server requests OAuth flow when a tool requiring authentication is invoked
  2. Token Request: Claude Code receives an authorization URL
  3. User Action: User opens the URL in a browser and approves access
  4. Token Callback: Authorization code returned to Claude Code
  5. Token Exchange: MCP server exchanges code for access token
  6. Tool Execution: Tool now has valid token for API calls

Configuring OAuth Servers

OAuth configuration is typically handled by the MCP server itself. Configuration in Claude Code:

{
  "mcpServers": {
    "github-server": {
      "command": "node",
      "args": ["./github-mcp.js"],
      "env": {
        "GITHUB_CLIENT_ID": "your-client-id",
        "GITHUB_CLIENT_SECRET": "your-client-secret",
        "GITHUB_REDIRECT_URI": "http://localhost:3000/callback"
      }
    }
  }
}

OAuth Token Management

For stdio servers:

  • Tokens are typically stored locally in server's cache directory
  • Claude Code does not manage tokens directly
  • Server handles refresh tokens automatically

For HTTP/SSE servers:

  • Server manages token storage (Redis, database, etc.)
  • Claude Code passes tokens in request headers
  • Server handles token expiration and refresh

Common OAuth Patterns

GitHub Integration:

{
  "env": {
    "GITHUB_CLIENT_ID": "...",
    "GITHUB_CLIENT_SECRET": "...",
    "GITHUB_APP_ID": "...",
    "GITHUB_PRIVATE_KEY": "..."
  }
}

Slack Integration:

{
  "env": {
    "SLACK_BOT_TOKEN": "xoxb-...",
    "SLACK_SIGNING_SECRET": "..."
  }
}

Google APIs Integration:

{
  "env": {
    "GOOGLE_CLIENT_ID": "....apps.googleusercontent.com",
    "GOOGLE_CLIENT_SECRET": "...",
    "GOOGLE_APPLICATION_CREDENTIALS": "/path/to/service-account.json"
  }
}

Managed MCP Configuration

For organizations needing centralized MCP server management:

Allowed MCP Servers

In managed settings, specify which MCP servers are permitted organization-wide:

{
  "allowedMcpServers": {
    "server-1": {
      "command": "node",
      "args": ["./dist/index.js"]
    },
    "server-2": {
      "url": "https://mcp.example.com"
    }
  },
  "allowManagedMcpServersOnly": true
}

Effect:

  • Only servers listed in allowedMcpServers are accessible
  • User and project settings cannot add additional servers
  • User settings can add servers only if allowManagedMcpServersOnly is not set

Denied MCP Servers

Block specific servers across the organization:

{
  "deniedMcpServers": [
    "untrusted-server",
    "legacy-server"
  ]
}

Effect:

  • Listed servers cannot be used even if configured elsewhere
  • Merges across all configuration scopes (user, project, managed)
  • Deny always takes precedence

Managed-Only Mode

{
  "allowManagedMcpServersOnly": true
}

When enabled:

  • User and project settings cannot define new MCP servers
  • Only allowedMcpServers from managed settings are used
  • deniedMcpServers still merges from all sources
  • Prevents shadow IT and unauthorized tool access

Troubleshooting MCP

Server Connection Issues

Problem: "Failed to connect to MCP server"

Possible causes and solutions:

  1. Stdio server not starting:

    # Test the command manually
node ./dist/index.js

# Check for syntax errors or missing dependencies
npm install
npm run build

  2. HTTP server unreachable:

    # Verify server is running
curl http://localhost:3000/health

# Check firewall rules
# Verify URL in configuration is correct

  3. Wrong working directory:

    {
  "mcpServers": {
    "server": {
      "command": "node",
      "args": ["./dist/index.js"],
      "directory": "/full/path/to/server"
    }
  }
}

Tool Not Found

Problem: "Tool not available from MCP server"

Solutions:

  1. Verify server is running: claude mcp list
  2. Check server exports the tool: claude mcp get server-name
  3. Restart Claude Code to refresh tool cache
  4. Check server logs for initialization errors

Environment Variable Issues

Problem: "API_KEY is undefined"

Solutions:

  1. Verify variable is set in shell before starting Claude Code
  2. Check configuration syntax in .mcp.json
  3. Use absolute paths for DATABASE_URL and similar
  4. Reload configuration: restart Claude Code

Performance Issues

Problem: "MCP server is slow or timing out"

Solutions:

  1. Increase timeout if supported: --env TIMEOUT=60
  2. Check server logs for bottlenecks
  3. Reduce payload size (large files, queries)
  4. Consider moving to HTTP transport for stdio server
  5. Monitor server resource usage (CPU, memory)

Debug Logging

Enable detailed MCP logging:

Via environment variable:

MCP_DEBUG=true claude code

Via configuration:

{
  "mcpServers": {
    "server": {
      "command": "node",
      "args": ["./dist/index.js"],
      "env": {
        "DEBUG": "mcp:*"
      }
    }
  }
}

Common Error Messages

Error Cause Solution
ENOENT: no such file or directory Command or script not found Check command and args paths
EADDRINUSE: address already in use Port already in use Change port or kill existing process
401 Unauthorized Invalid credentials Check API keys and environment variables
Connection refused Server not running Verify server startup command
Timeout Server too slow Increase timeout value

Validating MCP Server Configuration

Before committing to version control:

  1. Check JSON syntax:

    node -e "console.log(JSON.parse(require('fs').readFileSync('.mcp.json')))"

  2. Test server startup:

    node ./dist/index.js

  3. Verify tools are available:

    claude mcp list
claude mcp get server-name

  4. Remove secrets before committing:

    # Use environment variables instead
git status
# Ensure .mcp.json does not contain hardcoded secrets

Integration Examples

Integrating a Filesystem Server

{
  "mcpServers": {
    "filesystem": {
      "command": "node",
      "args": [
        "@anthropic-sdks/mcp-servers-filesystem"
      ]
    }
  }
}

Integrating a GitHub Server

{
  "mcpServers": {
    "github": {
      "command": "npx",
      "args": ["-y", "github-mcp"],
      "env": {
        "GITHUB_TOKEN": "ghp_..."
      }
    }
  }
}

Integrating a Database Server

{
  "mcpServers": {
    "postgres": {
      "command": "node",
      "args": ["./postgresql-mcp.js"],
      "env": {
        "DATABASE_URL": "postgresql://user:pass@localhost/dbname"
      }
    }
  }
}

Integrating a Remote API Server

{
  "mcpServers": {
    "external-api": {
      "url": "https://api.example.com/mcp"
    }
  }
}

Best Practices

  1. Use project-level configuration for team servers: Commit .mcp.json to version control for consistency across the team.

  2. Use user-level configuration for personal servers: Store personal tools in ~/.claude/.mcp.json, not committed.

  3. Store secrets in environment variables: Never hardcode API keys in configuration files.

  4. Use managed settings for organization: Large teams should use managed settings for consistent, enforced server lists.

  5. Test servers before adding to configuration: Verify the MCP server works independently before configuring it.

  6. Document custom servers: Include setup instructions in project README.

  7. Monitor server health: Regularly check server status with claude mcp list and /status.

  8. Version MCP servers: Keep track of which version of each MCP server is in use.

See Also

  • Settings Reference: Complete configuration reference
  • Permissions: Control which MCP tools Claude can use
  • Hooks: Extend MCP functionality with custom scripts
  • MCP Registry: Browse available public MCP servers
